Differences between RAID-1- and RAID-5
Contents
RAID 1 vs. RAID 5[edit]
RAID 1 and RAID 5 are two different levels of a redundant array of independent disks (RAID), a storage technology that combines multiple disk drives into a single logical unit.[1] The choice between RAID 1 and RAID 5 depends on the specific needs for data redundancy, performance, and usable storage capacity.[2] RAID 1 utilizes mirroring to create an exact copy of data on two or more disks, while RAID 5 uses disk striping with parity to protect data.[3]
RAID 1 offers a high level of data redundancy by creating identical copies of data across multiple drives.[4] This configuration is simple to implement and provides good read performance, as data can be accessed from any disk in the mirrored set.[5] However, write performance is comparable to that of a single disk. A significant drawback of RAID 1 is its low storage efficiency, as it uses only half of the total disk capacity for data storage, with the other half dedicated to the mirror.[2]
RAID 5, in contrast, provides a balance of performance, storage efficiency, and data protection.[2] It stripes data and distributes parity information across a minimum of three drives.[5] This allows for more efficient use of disk space compared to RAID 1, with the capacity equivalent of only one drive being used for parity. RAID 5 generally delivers good read performance but can have slower write speeds due to the need to calculate parity for each write operation. It can tolerate the failure of a single drive without data loss.
Comparison Table[edit]
| Category | RAID 1 | RAID 5 |
|---|---|---|
| Data Protection Method | Mirroring (exact data copy) | Striping with distributed parity |
| Minimum Number of Drives | 2[3] | 3[5] |
| Storage Efficiency | 50% (half of total capacity is usable)[2] | (N-1)/N (where N is the number of drives) |
| Fault Tolerance | Can withstand the failure of one or more drives, depending on the number of mirrors | Can withstand the failure of a single drive |
| Read Performance | Good to excellent, can be faster than a single drive | Good, as data is read from multiple drives simultaneously[2] |
| Write Performance | Slower, comparable to a single drive[3] | Can be slower than RAID 1 due to parity calculations[2] |
| Use Cases | Applications requiring high availability and redundancy, such as email servers and operating systems | File and application servers with a limited number of drives needing a balance of performance and storage |
Fault Tolerance and Data Recovery[edit]
Both RAID 1 and RAID 5 can sustain a single drive failure without losing data.[3] In a RAID 1 array, if one drive fails, the system continues to operate using the mirrored copy. The failed drive can be replaced, and the data from the functioning drive is then copied to the new drive.
In a RAID 5 array, if a drive fails, the data on the failed drive can be reconstructed using the parity information stored on the other drives. The array can continue to function in a degraded state until the failed drive is replaced and the data is rebuilt. However, the rebuild process for a RAID 5 array can be time-consuming and can impact performance. If a second drive fails before the rebuild is complete, all data in the array will be lost.
Performance Considerations[edit]
RAID 1 generally offers better write performance than RAID 5 because it does not have the overhead of calculating and writing parity.[2] For read operations, RAID 1 can offer good performance by reading from any of the mirrored disks.
RAID 5's read performance is typically strong because data is striped across multiple drives, allowing for parallel access.[2] However, its write performance can be slower due to the "write penalty," which involves reading the old data and old parity, then writing the new data and new parity. This makes RAID 5 less suitable for write-intensive applications.
